Docker ServiceNow Image Deployment: How to Implement

This guide follows the docker-servicenow-image repo: a production Docker image for ServiceNow nodes built from install.sh, pushed to Amazon ECR for use in ECS, EKS, or Lambda-style workloads.

Prerequisites

• Docker
• AWS CLI configured (credentials with ECR push permission)
• ECR repository (create once, below)

One-time: Create ECR repository

AWS_REGION=us-east-1
aws ecr create-repository --repository-name servicenow --region "$AWS_REGION"
# Note the repositoryUri, e.g. 123456789012.dkr.ecr.us-east-1.amazonaws.com/servicenow

Build and push to ECR

Set your ECR URI and optionally region/tag, then run the repo's script:

export ECR_URI=123456789012.dkr.ecr.us-east-1.amazonaws.com/servicenow
export AWS_REGION=us-east-1

./build-push-ecr.sh           # pushes as :latest
./build-push-ecr.sh v1.0.0    # pushes as :v1.0.0

Or in one line: ECR_URI=123456789012.dkr.ecr.us-east-1.amazonaws.com/servicenow ./build-push-ecr.sh v1.0.0

Runtime environment variables

When running the container (e.g. in an ECS task definition), set:

Variable	Required	Description
BUCKET	Yes*	S3 bucket containing the ServiceNow zip
KEY	Yes*	S3 key of the zip (e.g. artifacts/sn.zip)
JSON_PORTS	Yes	JSON array of ports, e.g. "[8443,9443]"
NODE_PORT	No	Which node to start (default 8443; use 9443 for worker)
JAVA_INSTALLER	No	Override Java package (default java-11-amazon-corretto-devel)

* If BUCKET and KEY are not set, the entrypoint skips install and starts the node under /glide/nodes (for pre-baked images).

Dockerfile (from repo)

The image uses Amazon Linux 2, runs install.sh at container start when BUCKET/KEY are set, then starts the chosen node via docker-entrypoint.sh.

FROM amazonlinux:2

RUN yum install -y -q --nogpgcheck \
 tar util-linux wget zip unzip gcc which vim curl nano zsh jq \
 glibc glibc.i686 libgcc rng-tools awscli \
 && yum clean all

ENV JAVA_INSTALLER=java-11-amazon-corretto-devel
RUN yum install -y -q "${JAVA_INSTALLER}" && yum clean all

WORKDIR /app
COPY install.sh /app/install.sh
COPY docker-entrypoint.sh /app/docker-entrypoint.sh
RUN chmod +x /app/install.sh /app/docker-entrypoint.sh

ENV NODE_PORT=8443
ENV JSON_PORTS="[8443,9443]"
ENTRYPOINT ["/app/docker-entrypoint.sh"]

Run locally (after push)

aws ecr get-login-password --region us-east-1 | docker login --username AWS --password-stdin 123456789012.dkr.ecr.us-east-1.amazonaws.com

docker run -e BUCKET=my-bucket -e KEY=path/sn.zip -e JSON_PORTS='[8443,9443]' -e NODE_PORT=8443 \
  -p 8443:8443 \
  123456789012.dkr.ecr.us-east-1.amazonaws.com/servicenow:latest

Repo files (schema)

File	Role
Dockerfile	Amazon Linux 2 base, deps + Java; runs install.sh at container start via entrypoint
docker-entrypoint.sh	Runs install.sh when BUCKET/KEY set, then starts chosen node's startup.sh
build-push-ecr.sh	Builds image and pushes to ECR (requires ECR_URI)

Takeaways

• Use docker-servicenow-image for a production ServiceNow node image: install.sh + docker-entrypoint.sh, ECR via build-push-ecr.sh.
• Parameterize with BUCKET/KEY for install-at-start or omit for pre-baked; set NODE_PORT and JSON_PORTS for the node to start.
• Same image runs in ECS, EKS, or locally; keep credentials and instance URL out of the image (env or secrets at runtime).
